Reference: BOXled1418-12V
Brand: WAS
control box for LED lights 12V LM2
control box for LED lights 12V LM2
This eshop uses cookies to provide services, customize your ads, and analyze your traffic. More information | Accept all cookies Personalise |
| Accept selected cookies |



for voltages from 10V to 30V
it shines with white continuous light and intermittent orange light
the possibility of simultaneous lighting of both lights
current consumption at 13.8V: 0.7A (9.7W)
current consumption at 13.8V orange light: 0.4A (5.5W)
luminous flux 1200lm (white light)
light color 6000K (white light)
radiation angle approx. 20°
10 pcs 1W SMD chips (white light)
6k pcs 1W SMD chips (orange light)
aluminum body: width 157mm x height 48mm x depth 47mm (without bracket)
lens material: PMMA
length of power cable: 19cm
bracket mounting, M8 screw
wiring:
black wire - minus
red wire - white light
white wire - orange intermittent light
Reference: BOXled1418-12V
Brand: WAS
control box for LED lights 12V LM2
luminous flux 1200lm
