The 24VDC/12VDC switching power supply ensures the operation of 12V appliances from a 24V battery with an efficiency of approx. 90% Power supply 21–30V Permanent output current 15A + – 1 A
Maximum instantaneous output current 20 A
Input voltage 21 – 30 V
Output voltage 12 – 14 V
Undervoltage protection threshold 18 – 21 V
Threshold value of overvoltage protection 30 – 33 V
Permissible operating temperature 0 – 40 °C
