The tester is compatible with the following batteries:
Acid/lead (regular/regular batteries)
Flat/plate AGM
Spiral AGM
Gel
EFB
Testing 6V and 12V batteries and a wide measurement range from 2AH to 220AH
Available 11 languages including Polish (English, Spanish, German, French, Italian, Russian, Portuguese, Japanese, Chinese, Korean).

The tester allows you to measure:
voltage and % battery charge / battery test
inrush current / crank test
alternator operation / charging test
internal resistance/battery resistance
Power standards
About 100-2000
JIS 26A17–245H52
DIN 100-1000
IEC100-1000
EN 100-2000
SAE 100–2000
BCI 100– 2000
MCA 100–2000
CA 100-2000
GB 2-220AH

Other functions:
Quick battery test
Viewing and saving the performed tests
Parameter preview in in the form of a graphic chart
One of the most interesting functions is to take a screenshot (PrintScreen) by simultaneously pressing two buttons up and down for 3 seconds. We can take 5 screenshots and then connect the device to the laptop with a USB cable and print from the SNAPSHOT folder, for example, the saved measurement, graph or other parameter whose screenshot we took.

Battery test in:
cars, motorcycles, scooters, alarm control panels, UPS emergency power supply, Cordless tools and many more.

Operating environment temperature: 0*C to 50*C
Storage temperature: -20*C to 70*C
Housing material: acid-resistant ABS plastic
Battery capacity measurement range: 2Ah-220Ah
Voltage/use: 6V and 12V
Input voltage: 5V~20V

Condition measurement results battery in %:
SOC – battery state of charge
SOH – degree of battery wear

The set includes:
tester
USB cable for printing
style="color:#4f4f4f;font-family:sans-serif;font-size:12.8px;font-weight:400;background-color:#ffffff;">User Manual
Original cardboard packaging
Additional batteries and accumulators are not needed to power the device, because it draws energy directly from the tested car battery.

Wired connection:
Red (+)
black (-)
The device works as soon as it is connected to the source under test energy. Detects bad batteries.
Protection against wrong polarity connection. A bad connection will not damage the tester/battery/car.
Direct battery test with charge drops. It is not necessary to fully charge the battery before testing.
The battery test is mainly focused on the analysis of the service life by calculating its current capacity and degree of wear. Thanks to it, you can assess whether the battery needs to be replaced.
Thanks to the test, you will assess whether the battery supplies the car with the correct current when starting and running the engine.
The charging test allows analyze the vehicle's charging system and verify that the voltage in the electrical system is correct.
advantages:
Simple and easy to use
Test the battery inside and outside the vehicle (selection from the menu)
Large readable color LCD display
Test results based on CCA, CA, JIS, EN, DIN, SAE, IEC, BCI, MCA, GB standards.
Testing the vehicle's starting system: starting time, voltage and condition
Vehicle charging system test: load voltage, unloaded voltage
AH range: 2-220AH
Device dimensions:
height: 12 cm
width: 6.5 cm
thickness: 2 cm
length of measuring cables: 70 cm
